Course Description:

Blueprint reading introduces reading and interpreting blueprints with a focus on reviewing common elements, the alphabet of lines, and the differences between types of drawings. Also provides dimension definitions for height, width, and depth, and reviews dimension and geometric symbols and datums. Enhances the learner’s math and geometry knowledge through practical application.

Course Outline:

Blueprint Lines, Blueprints, Blueprint Views, Blueprint Dimensions and Notes, Blueprint Process Drawings

Course Segments:
